- SORALUCE SORA 4 milling machine
This SORALUCE SORA 4 milling machine was built in the year 1989 in Spain. It is equipped with a SIEMENS SINUMERIK 810 control unit. The machine has a spindle speed of 15-1600 rpm.
Overview
- brand: Soraluce
- year: 1989
- MODEL: SORA 4
- application type: Milling
- Location: Spain
- machine type: CNC Milling Machine
- availability: Sold
- control unit brand: SIEMENS
Technical Information - Soraluce SORA 4
General Data
- Measurements width: 9800 mm
- Measurements depth: 4050 mm
- Measurements height: 3600 mm
- Machine weight: 24000 kg
Control Unit
- Model: SINUMERIK 810
- Brand: SIEMENS
Main drive
- Spindle speed range: 15 - 1600 rpm 1/MIN
- Spindle motor power: 18 kw
Movement
- X-AXIS Movement: 4000 mm
- Y-AXIS Movement: 1000 mm
- Z-AXIS Movement: 1600 mm
Table
- Outer length: 4000 mm
- Outer width: 1000 mm
- Table load: 10000 kg
Additional Information
- Technical Machine Benefits:
- - Spindle model: automatic axes a/b - a 2,5º-b 2,5º.
- - Cone: iso 50
- - Tool magazine: 60 units
- - Chip extractor: yes
Machine Benefits
*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
