Quaser HX404 Horizontal Machining center

Show in original language

This Quaser HX404 Horizontal Machining center was manufactured in the year 2016 in Taiwan. It is equipped with a Fanuc 31 LB control unit. The machine has a spindle speed of 15000 rpm.

Overview

brand: Quaser
year: 2016
MODEL: HX404
application type: Milling
Location: Germany
machine type: Horizontal Machining Centre
availability: Sold
control unit brand: FANUC

Technical Information - Quaser HX404

General Data

Measurements width: 2365 mm
Measurements depth: 4915 mm
Measurements height: 2895 mm
Machine weight: 10500 kg

Control Unit

Model: 31 LB
Brand: FANUC

Main drive

Spindle speed range: 15000 1/MIN
Spindle motor power: 26 kW

Movement

X-AXIS Movement: 560 mm
Y-AXIS Movement: 640 mm
Z-AXIS Movement: 640 mm
B-AXIS Movement: 360º MM

Tools

Type of tool holder: BT 40

Additional Equipment

- pallet is included
- No zero point clamping systems included
- 1x hydraulic power unit (motor)

Additional Information

Machine Benefits

Technical Machine Benefits:
- - Number of tool magazine positions 60
- - Tool changing time [sec] 1. 4 max. Tool diameter [mm] 76 max. Tool diameter with free adjacent space [mm 125 tool length max. [mm] 350 tool weight max. [kg] 7
- - Coolant system
- - Volume of coolant tank [l] 650 internal coolant supply pressure [bar] 20 internal coolant supply [l/min] 25 jet cooling pressure [bar] 3 jet cooling [l/min] 60 chip flushing pressure [bar] 1. 5 chip flushing [l/min] 25 coolant spray gun yes
- - Heat compensation
- - Temperature-controlled oil cooling system for main spindle yes cooled ball screws
- - Lectrical connected load: 41 kva
- - Required pneumatic connection [bar] 6 hydraulic unit yes hydraulic oil tank [l] 200
- - Pallet size: 400 x 400 mm
Qualitative Machine Benefits:
- - Maximum swing diameter: 630 mm
- - Pallet change time: 5,5 s
- - Maximum loading weight: 400 kg
- - Maximum height on pallet: 900 mm
- - Main spindle torque max. [nm]: 177
- - Tool holding system: bt40fc

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
