Used Lathe Mazak QUICK TURN 10 (2000) for sale | GINDUMAC.COM

Show in original language

This 2-Axis lathe was manufactured in 2000. The MAZAK QUICK TURN 10 features a standard machining diameter of 100mm, a turning length of 256mm, and supports an 8-position tool turret. Key specifications include a main spindle speed of 60-6000 rpm, rapid traverse speeds up to 30.5 m/min (X) and 33 m/min (Z), and a hydraulically operated 3 cam chuck system. Ideal for detailed and precise machining tasks, the MAZAK QUICK TURN 10 machine we have for sale is robust and reliable. For more details, contact us today.

Overview

brand: Mazak
year: 2000
MODEL: QUICK TURN 10
production hours: 17818
application type: Turning
Location: Germany
machine type: Horizontal Turning Machine
availability: Sold

Technical Information - Mazak QUICK TURN 10

General Data

Machine weight: 2750 kg

Main drive

Number of spindles: 1
Spindle speed range: 60-6000 1/MIN
Spindle bore: 50mm
Number of axis: 2

Movement

X-AXIS Rapid traverse: 30.5 m/min
Z-AXIS Rapid traverse: 33 m/min

Turret

Number of turrets: 1

Tools

Number of stations: 8

Additional Equipment

- Tool holders as basic equipment included.

Additional Information

Machine Benefits

Technical Machine Benefits:
- - Working area: max. Swing diameter 300mm, standard machining diameter 100mm, turning length 256mm
- - Constant torque 96 nm
- - Tool turret: standard 8-position design, holds mk1/mk2 drills
- - Traverse path: x 100mm, z 290mm
- - Hydraul. 3 cam chucks, complete coolant system, tailstock mk4 travelling distance 325mm
Qualitative Machine Benefits:
- - Tool calibration sensor / automatic measuring arm.

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
